Magpul MOE Carbine Stock – Mil-Spec
$119.95
ASK US A QUESTION
Please send us your inquiry about this product using the below form. The Delta Mike team monitor this inbox periodically throughout the day.
Description
Magpul MOE Carbine Stock – Mil-Spec
The MOE Carbine Stock – Mil-Spec model (Magpul Original Equipment) is a drop-in replacement buttstock for AR15/M16 carbines using Mil-Spec sized receiver extension tubes. Designed for light, fast action the streamlined A-frame profile avoids snagging and shields the release latch to prevent accidental activation.
The Mil-Spec Model includes a standard 0.30″ thick rubber butt-pad which provides positive shoulder purchase to prevent slippage even with body armor or modular gear.
DEPENDABLE AR STOCK
Mounts on Mil-Spec sized carbine receiver extension tube
SECURE FIT
Premium chrome-silicon lock spring provides positive locking and long service life
THE RIGHT BALANCE OF CHEEK WELD AND COMFORT
Sloping cheek weld combines a slim profile with user comfort
Side mounting slots accept optional cheek risers for NON AR15/M4 applications
SET IT AND FORGET IT
Shielded release latch prevents snagging and accidental operation
IMPACT MITIGATION
Removable 0.30″ Rubber Butt-Pad offers an anti-slip surface and increases impact protection
SLING POINT OPTIONS
Compatible with Magpul ASAP®, ASAP® QD, and other receiver-mount sling attachments.
Sling Mounts:
Rear/Bottom – 1.25″ sling loops
Toe – Lanyard hole for custom para-cord rigs
* Specifications based on standard-length (flat-back) M4 Carbine receiver extension and may vary depending on tube manufacturer.
NOTE: There are two basic sizes of M4 Carbine receiver extensions (buffer tubes): Mil-Spec and Commercial-Spec. If you have a Commercial-Spec size extension on your rifle, make sure to order the Commercial-Spec MOE.
Specifications:
| Platform | AR10, AR15, M4, M16, M110, SR25 |
| Compatibility | Mil-Spec sized carbine receiver extension tube (not included) from manufacturers such as Colt, LMT, Ruger, S&W, SIG, and others |
| LOP, M4 Collapsed | ~10.5 in. |
| LOP, M4 Extended | ~13.8 in. |
| LOP Adjustment Range | 3.3 in. |
| Length, max | 6.9 in. |
| Weight | 8.0 oz. |
| Weight, w/ receiver extension | 12.0 oz. |
Additional information
| Colour | Black, Olive Drab, Stealth Grey |
|---|---|
| Make | AR15 |
Brand
Magpul
Disclaimer
Please be aware that some firearm parts may require fitting or adjustment due to variations between individual firearms and normal manufacturing tolerances. If you are not confident in your ability to correctly install or fit a part, we strongly recommend having the work carried out by a qualified gunsmith. The fit, function, and safe operation of all installed parts must be thoroughly checked before live firing. Delta Mike Ltd accepts no responsibility for damage resulting from incorrect installation, fitting, adjustment, or use of these parts.
