Guide TB650-Pro 50mm Thermal Clip on – LRF
$3,299.95
Out of Stock
Email when available
ASK US A QUESTION
Please send us your inquiry about this product using the below form. The Delta Mike team monitor this inbox periodically throughout the day.
Description
Guide TB650-Pro 50mm Thermal Clip on – LRF
After an in-depth hardware upgrade and software optimization, the TB LRF Pro Series combines precision and portability. Its appearance remains light without reducing professionalism at all: built-in laser rangefinder can reach an ultra-long distance of up to 1,000 meters; two batteries empower a longer operating time; the full HD AMOLED display brings a rich and detailed visual experience; it also supports intelligent functions such as image tracing, automatic recording, AI tracking, etc.
Features:
- 12um infrared detector: TB LRF Pro Series adapts the high-sensitive 12um infrared detector with NETD down to 20mK. The advanced detector can distinguish the slightest differences and changes in temperature.
- 1000m laser rangefinder: The built-in LRF module provides a long laser rangefinder of up to 1000m, enabling users to detect and locate the targets quickly and precisely.
- FuII-HD 1920×1080 AMOLED display: TB LRF Pro Series is equipped with a 0.39″ AMOLED 1920×1080 display screen, presenting a vivid image with more details for users.
- IP68 dustproot & waterproof: Compact and rugged, portable and powerful, the TB LRF Pro Series shares the high protective features of lP68, to support your outdoor adventures in the harsh environment.
Specifications:
| Sensor Type | Uncooled VOx Infrared Detector, 8 to 14 µm |
| Resolution | 640×512@12µm |
| NETD | 20mK |
| Frame rate | 50Hz |
| Objective lens | 50mm, F1.0 |
| Field of view | 8.8°×6.6° |
| FOV m @100m | 15×12 |
| Magnification | 1x |
| Detection range | 2600m/ 2800yd |
| Display Type | 0.39” AMOLED 1920×1080 |
| Color palettes | White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia |
| Laser Range Finder | 1000 m / 1090 Yards |
| WIFI | 2.4G, 5G |
| Interface | USB Type-C (Power supply/USB2.0) |
| Other | Microphone, Bluetooth, Recording function (Photo/Video, Audio recording included) |
| Memory capacity | 64GB |
| Battery type | 2 18650 batteries |
| Operating time | 9 hours |
| Operating temp. | -20 °C to 50 °C / -4°F to +122°F |
| Shock | 1000 G at 1 ms half sine pulse (as per IEC60068-2-27) |
| Encapsulation | IP68 |
| Weight (g/oz) | 582/ 20.53 |
| Size (mm/in) | 161×89×97mm / 6.34×3.50×3.82″ |
| Eyepiece Exit pupil distance | 20mm |
| Zoom | 6.8x |
